The Peterson VSS-C StroboStomp Classic Tuner is the most fully-featured pedal tuner made by anyone to date. A high-contrast LCD screen makes this tuner the perfect choice for both indoor and outdoor use as well as for anywhere that lighting conditions are less than ideal. Integrated, fold out, steel mounting lugs at the unit’s bottom rubberized plate keep it in place on your pedal board without unsightly tape or messy adhesives. Its ultra-robust die-cast chassis and Switchcraft brand input/output jacks assure a quality tuning even after the roughest of voyages. Also, its unique quick- release battery-access door steers you far away from having to deal with delicate, easily broken, battery lead wires. Battery changes are a breeze!

The professional-quality active DI on board is mutable and lets you select one of three stages of signal attenuation—all while remaining 100% true bypass. Finally, the tuner’s side mounted USB jack makes your unit future-proof and custom tailored to be exactly what you need it to be by allowing Mac or PC connectivity for updates and unit user programming/modifications.

TRUE STROBE TUNING IN A PEDAL

Building off the success of the legendary StroboStomp™ pedal, the Stomp Classic™ is a workhorse that will enhance any pedalboard. From the true-bypass signal flow to the active, on-board direct box. We have redefined the standard and created the ultimate pedal tuner.

HIGH DEFINITION TUNING

All Peterson products provide guaranteed tuning results to within +/-0.1 cent. That is 1/1000th of a fret! The large 2.25" , high-contrast screen is easy to see on your pedalboard amongst stage lights or out in the sun.

Tuning with the Stomp Classic™ allows your instrument to sound its best and helps ensure its tuning stays true during playing.

This level of accuracy is the highest in the industry and what has made Peterson the choice of professionals around the globe for over 65 years.

Default

EQU
Standard tuning temperament suitable for regular or alternate tuning, 100 cent intervals - no Sweetening.

Guitar & Bass

GTR
Peterson Exclusive Sweetened tuning for guitar, especially good for guitars with three saddle bridges and short-scale electric guitars.
ACU
Peterson Sweetened tuning for acoustic guitar in standard tuning. Compensates for string deflection caused by fretting and capo use.
DAD
Peterson Sweetened tuning for acoustic guitar in modal DADGAD tuning with optimized fifths.
G12
Peterson Sweetened tuning for 12 string guitars with regard to the string courses.
BRT
Peterson Sweetened tuning for baritone guitars.
7ST
Peterson Sweetened tuning for seven string guitars.
BAS
Peterson Sweetened tuning for bass guitar when playing with acoustic piano.
BSn
Displays string numbers instead of note names for 4 and 5 & 6 string bass guitars 543210 instead of BEADGC).
GTn
Displays string numbers instead of note names for 6 & 7 string guitars (7654321 instead of BEADGBE).

Buzz Feiten

BFE
Tuning and intonation offsets for electric guitars equipped with the Buzz Feiten Tuning System. (Buzz Feiten Tuning System is a registered trademark of Buzz Feiten Design).
BFB
Tuning and intonation offsets for electric bass guitars equipped with the Buzz Feiten Tuning System. (Buzz Feiten Tuning System is a registered trademark of Buzz Feiten Design).
BF12
Tuning offsets for 12 string guitars equipped with the Buzz Feiten Tuning System*. (Buzz Feiten Tuning System is a registered trademark of Buzz Feiten Design).
BFA
Tuning offsets for acoustic guitars equipped with the Buzz Feiten Tuning System*. For Buzz Feiten Acoustic intonation work, a Peterson AutoStrobe 490 is recommended. (*Buzz Feiten Tuning System is a registered trademark of Buzz Feiten Design).

Steel Guitar

SE9
Peterson Pedal Steel Guitar Sweetened Tuning for 10 string pedal steel in E9 tuning. This is based on Jeff Newman's later system where the E strings are sharp of concert pitch.
SC6
Peterson Pedal Steel Guitar Sweetened Tuning for 10 string pedal steel in C6 tuning. This is based on Jeff Newman's system (www.jeffran.com)
OE9
Peterson Pedal Steel Guitar Sweetened Tuning for 10 String pedal steel in E9 tuning. This is based on Jeff Newman's earlier system where the E strings are at concert pitch.
U12
Peterson Pedal Steel Guitar Sweetened Tuning for 12 string universal pedal steel guitar in E9/B6 tuning. This contains the offsets for the open strings based on Jeff Newman's system.
LA6
A6 settings for lap steel guitar.
LC6
C6 settings for lap steel guitar.

Bluegrass

dbO
Pure tuning for open A, D and G tunings for Dobro**/Resonator guitars. The major thirds in each tuning will be beatless perfect intervals. (**Dobro is a registered trademark of Gibson Guitar Corp.
BJO
Peterson Sweetened tuning for 5 string banjo in G tuning, sweetens the major third B string.
MAN
Sweetened tuning for mandolin, mandola & mandocello, string deflection offsets.
dbH
Half-tempered tuning for open A, D and G tuning for Dobro** & Resonator guitars. (**Dobro is a registered trademark of Gibson Guitar Corp.

Orchestral

VLN
Perfect 5th intervals for 4 and 5 string violin.

Compare to Sweetened Tunings offered in other products.

STUDIO QUALITY ACTIVE DI

High-impedance signals get balanced and matched with ultra-transparency, extreme detail and sparkle. Perfect for use with acoustic or bass guitars, electric pianos and synthesizers. Fully mute-able for private tuning at the gig between songs.

Three step attenuation pad reduces the incoming signal level from loud sources that could overload the circuit and cause distortion. Selectable ground lift reduces noise and helps prevent ground loop hum in your rig.

High-quality Neutrik® XLR jack for optimum reliability and roll cage bar to protect your XLR cable on stage from accidents.

IT'S YOUR SOUND

Enjoy transparent operation no matter its location in your signal chain.

LET'S CONNECT

Connect the Stomp Classic to your Mac or PC to customize the included tunings or load in the tunings you've created with our Peterson Connect online utility.

RUGGED. RELIABLE. ROADWORTHY.

The Stomp Classic™ is built like a tank and capable of taking the most grueling punishment.

We have designed this to be the most roadworthy tuner you can place on your pedalboard.

BUILT TO LAST

A heavy duty, die-cast chassis with a 3PDT stomp switch makes the Stomp Classic™ road-worthy and reliable. The 9V battery drop is located under the pedal and is easily accessed with one finger for quick loading before the gig.

No more thumbscrews to remove or battery doors to lose.

The thick rubber matting securely grips even the most abused of stages. For those looking to permanently mount the Stomp Classic™, flip-out mounting tabs are located on the bottom of the unit.

Power Supply: Optional (9VDC Negative Center Pin)

DI: Active/Mutable/3-Stage Attenuable

Peterson Connect Compatible: Yes

Note Range: C0 - A#8

Note Selection: Automatic

Form Factor: Pedal / Floor

Accuracy: 0.1 Cents

Display Type: LCD

Display Resolution: 256 Segments (128 per row )

Construction: Die Cast

Product Dimensions LxWxH: 6" x 3.25" x 2.75"

Product Weight: 1.7lbs

USB Port: Yes

USB Type: Mini

Rechargeable: No

Battery Type: 9V (Included)

Power: 9VDC 80mA (Nominal)

Built-In Microphone: No

Built-In Speaker: No

Headphone Jack: No

Inputs: 1/4" Mono

Outputs: 1/4" Mono ( through ), Balanced XLR Output

Mute-able Output: Yes

Concert A Range: 390Hz to 490Hz

Transposition Range: -6 to +5

Frequency Response Range: 16.35Hz - 7302Hz

Warranty: 3 years

Sweetened Tunings: 25

User Presets: 10 Locations

Historic Temperaments: Equal Only

I've installed Peterson Connect for Google Chrome. My device is plugged in, but it says 'No Device Detected'

For Peterson Connect to detect your device, your operating system needs to first install drivers and mount the USB device. This can take a few minutes on a Windows machine, and a few seconds on Mac. If your operating system is not aware of a connected device, Peterson Connect will not be able to detect it.

If your system is not detecting the USB device, it is either an issue with the cable, USB port ( on the device or computer ) or a problem with the device itself.

Here's how to check if Mac OS X detects your Peterson Device.

https://support.apple.com/en-us/HT203001

Click the USB tab. ( Press Command 'R' to refresh the USB list if you've connected since opening the System Report )

Windows users can locate the StroboPLUS HD in the device manager under Sound, Video and Game Controllers, and the Stomp Classic as a standard HID compliant device under Human Interface Devices

Some Windows users have found that connecting to a different USB port solves the problem. Windows will install new drivers for each USB port.

Peterson Connect for Google Chrome and OSx versions lower than 10.8 may or may not function properly. Due to these operating systems no longer being distributed, Peterson can not properly test for 100% compatibility. The legacy stand-alone desktop application however, was tested on these platforms when it was initally released and is still compatible for firmware update operations.

Download the dmg file from this link, open and drag all contents of the package to your applications folder.

http://www.petersontuners.com/firmware/PetersonConnect_1_0_3.dmg

Upon connecting your device with the USB cable you should see a product logo and icon. Don't worry about the 'Account Settings' on the desktop app. Any firmware updates will show up under 'Updates'

Share this FAQ Entry

Was this helpful?

Help others find this information sooner.

Is the accuracy the same for all Peterson tuners?

Yes, the accuracy is within 0.1 cents (1/1000 of one semitone) as with all Peterson Strobe Tuners. An important thing to note is that Peterson Strobe Tuners have ultra high definition displays, so not only are they highly accurate in detecting a note but they have the ability to display that accuracy. Other products claim accuracy but do not have the high definition screen to display the level of accuracy in which they claim. If you cannot see the accuracy, it is of little value. Only Peterson provides High Definition Strobe Tuning.

Share this FAQ Entry

Was this helpful?

Help others find this information sooner.

How do I read a strobe display?

Basically, the strobe image appears to travel to the left if your instrument is flat of the desired pitch and to the right if it is sharp. On earlier models such as the StroboStomp 1, StroboStomp 2, VS-1, VS-II and V-SAM, the strobe image travels upward if your instrument is sharp and downward if your instrument is flat of the desired pitch.

Adjust your instrument until the pattern is as close to still as possible. Strobe displays are 'real-time' and extremely high definition. They require very precise tuning adjustments to stop the display because the frequency/pitch of any instrument is never totally stable.

You'll quickly learn to read the display, make the most precise adjustments and appreciate the high resolution that only a Peterson provides.

Share this FAQ Entry

Was this helpful?

Help others find this information sooner.

What should I do if my new Peterson product doesn't seem to work properly?

If you've first tried all of the solutions offered here, please contact Peterson directly. It is important that you do NOT return the product to the store in which you purchased it without Peterson instructing you to do so. If your unit is problematic, we would like to limit the chances of another customer purchasing the returned unit. Always arrange for product service or replacement directly with Peterson.

Share this FAQ Entry

Was this helpful?

Help others find this information sooner.

What features of my Stomp Classic can I configure with Peterson Connect?

  • Configure the order and number of sweetened tunings in your device's available tuning list.
  • Design up to 10 custom presets using the tunings from your sweetened tunings list.
  • Create your own sweetened tunings with custom offsets and note names.

Share this FAQ Entry

Was this helpful?

Help others find this information sooner.

There are no entries matching your search.

Not finding an answer? Open a support ticket for personalized support of your Peterson product.

View More

StroboStomp Classic English Manual

Not finding an answer? Open a support ticket for personalized support of your Peterson product.

Stomp Classic Version 1.0.05

Tuesday, September 24, 2013 9:40:00 AM EDT

  • Various Bug Fixes

Stomp Classic Version 1.0.04

Wednesday, August 7, 2013 10:37:00 AM EDT

  • Note display default is now the sharp ( # ) version of en-harmonic equivalents. Previously a combination of sharps and flats ( #/b ) were used.
  • Peterson Connect now supports characters P and L for custom octave names ( Pedal and Lever indicator for Steel ).

Stomp Classic Version 1.0.02

Sunday, January 1, 2012 2:01:30 PM EST

  • Enables Peterson Connect functionality
  • Various Bug Fixes.
